Highlights:
Color: Yellow
Contact Coating: Zinc
Contact Material: Steel
Height: 5.46 Inch
Housing Material: Polypropylene
Length: 1-1/32 Inch
Mounting Type: Screw
Temperature Rating: 221 deg F
Type: Twist-On
Voltage Rating: 300/600 V
Width: 23/32 Inch
Wire Size: 22 to 10 AWG
Wings are knurled for a sure grip and offset from centerline for greater twisting leverage
Square-wire zinc-plated spring instantly adjusts to the shape and size of the splice
Flame-retardant properties resist heat distortion up to 221 deg F
High-dielectric shell features deep skirt design to prevent exposure of bare wire
Rated at 600 V max in building wire and at 1000 V max in lighting, fixtures/luminaries and signs
Copper to copper connections only
